The P2 suspended light fitting can light up open spaces for a high technology start-up, media library corridors, legal firm meeting rooms, a luxury hotel lounge, the indoor area of a clothing store, leading Champagne wine cellars, etc.

The Quadratube P2 suspended light fitting with its “Seam-style” louvre and perforations

The P2 suspended light fitting with its sleek rectangular outline supported by two wires and a discrete power cable is a great combination of design and performance. This model provides mellow lighting with optimal visual comfort for residential settings and workplaces thanks to its built-in LED module, deflector and glare-free louvre. The louvre perforations create lateral light points which subtly diffuse light in a rather captivating manner.

Access to product information

A stylish sleek outline

Functional lighting in a high-end luminaire. The P2 suspended light fitting with its sleek rectangular outline adds a subtle distinguished touch to any type of residential, business or retail environment. Its clean sophisticated design fits nicely in, adding an undeniable touch of elegance to any location.

This luminaire brings remarkable visual comfort with UGR < 16

The P2 is fitted with a built-in LED module, a deflector and a glare-free louvre reaching up to UGR < 16 for some versions (UGR<19 for other versions), and bathes residential settings and workplaces (offices, meeting rooms, reception areas) in mellow light, ensuring exceptional visual comfort. Its perforations create lateral light points which catch the eye. This architectural light combines a contemporary feel with visual comfort and quality lighting.

An adaptable multi-purpose luminaire

The P2 suspended light fitting is available in two lengths (1.3 m and 1.6 m) and four different reflector colours (silver, Champagne, copper and petrol) and fits in nicely with any architectural project. Each finish brings its own special touch, with customised lighting to match your preferred atmosphere. Thanks to its LED module, with a dimmer option, you can also adjust the lighting levels to meet your requirements.

Detailed workmanship from France

The P2 luminaire benefits from Sammode”s industrial know-how and was designed in partnership with Jean-Michel Wilmotte and produced at our French plant. Each detail was carefully designed, tested and validated to guarantee effective lighting with technical expertise and quality manufacturing. The way the power cable is smartly fitted in a notch at the top reflects the attention paid to every last detail. Exceptional French lighting.

Quadratube by Wilmotte: when tubes turn rectangular!

Jean-Michel Wilmotte has totally transformed the iconic tubular luminaire by opting for a sleek and elegant rectangular shape. This contemporary design stands along side subtle vintage references, adding a classy timeless touch to the Quadratube collection. Sammode DNA is still clearly visible, but part of a totally new range of luminaires, where every little detail reflects detailed workmanship.

Sammode expertise

Designed and manufactured in France

Designed and manufactured in France, keeping supply chains short and using durable components and materials, primarily sourced in Europe. Each luminaire is manufactured, assembled and inspected by our teams with full traceability.

8-year warranty

Our products are designed to be upgraded along with your set-up, which means that they come with a 8-year warranty and guaranteed availability for the accessories you need, today and into the future.

Totally repairable in the long-term

Unlike the disposable world we live in, our designer lights are meant to last. We carefully select our luminaire components and commit to providing spare parts well into the future. The light source is also easy to replace.

Références principales et téléchargements

Plaquette produit

Eulumdat

Notice

Certificat
Tout télécharger

Pendant light

Non dimmable - 2700K

ReflectorFlux (lm)L (mm)DesignationCodeWatt Data sheet Plan STEP DS .TXT Download all
Silver 3470 1316 QT SUSP GRD S 1300 MP-827 C3M 70100035 40 Data sheet Plan STEP DS .TXT Download all
Silver 4340 1616 QT SUSP GRD S 1600 MP-827 C3M 70100036 50 Data sheet Plan STEP DS .TXT Download all
Champagne 3110 1316 QT SUSP GRD CH 1300 MP-827 C3M 70100027 40 Data sheet Plan STEP DS .TXT Download all
Champagne 3890 1616 QT SUSP GRD CH 1600 MP-827 C3M 70100028 50 Data sheet Plan STEP DS .TXT Download all
Copper 2910 1316 QT SUSP GRD CB 1300 MP-827 C3M 70100021 40 Data sheet Plan STEP DS .TXT Download all
Copper 3630 1616 QT SUSP GRD CB 1600 MP-827 C3M 70100022 50 Data sheet Plan STEP DS .TXT Download all
Petrol 1860 1316 QT SUSP GRD P 1300 MP-827 C3M 70100033 40 Data sheet Plan STEP DS .TXT Download all
Petrol 2330 1616 QT SUSP GRD P 1600 MP-827 C3M 70100034 50 Data sheet Plan STEP DS .TXT Download all

Pendant light

Casambi dimmer - 2700K

ReflectorFlux (lm)L (mm)DesignationCodeWatt Data sheet Plan STEP DS .TXT Download all
Silver 3470 1316 QT SUSP GRD S 1300 MP-827 RB C3M 70100007 40 Data sheet Plan STEP DS .TXT Download all
Silver 4340 1616 QT SUSP GRD S 1600 MP-827 RB C3M 70100016 50 Data sheet Plan STEP DS .TXT Download all
Champagne 3110 1316 QT SUSP GRD CH 1300 MP-827 RB C3M 70100003 40 Data sheet Plan STEP DS .TXT Download all
Champagne 3890 1616 QT SUSP GRD CH 1600 MP-827 RB C3M 70100012 50 Data sheet Plan STEP DS .TXT Download all
Copper 2910 1316 QT SUSP GRD CB 1300 MP-827 RB C3M 70100009 40 Data sheet Plan STEP DS .TXT Download all
Copper 3630 1616 QT SUSP GRD CB 1600 MP-827 RB C3M 70100018 50 Data sheet Plan STEP DS .TXT Download all
Petrol 1860 1316 QT SUSP GRD P 1300 MP-827 RB C3M 70100005 40 Data sheet Plan STEP DS .TXT Download all
Petrol 2330 1616 QT SUSP GRD P 1600 MP-827 RB C3M 70100014 50 Data sheet Plan STEP DS .TXT Download all

Color temperature

2700K 827
3000K 830/930
4000K 840/940

Lighting management

Electronic gear unit for DALI dimming RD
Electronic gear unit for push button RS
Switch-off warning function (for sensor/timer) RC
Permanent standby mode 10% function RCP
Casambi Bluetooth control RB

Technical specifications

Designer
  • Jean-Michel Wilmotte

Light source
  • High-efficiency removable LED module (CRI>80, 3 SDCM)
  • 70 000 h L80/B10 at max. operating temperature
  • Photobiological hazard : Group 1
Reflector
  • Inclined slats louvre, "Couture" perforations - made of anodised aluminium
  • Specific satin-finish primary diffuser optics
Lighting comfort
  • Very low glare: UGR ≤19
  • Transversal eye protection angle (louvre): 31°
  • Longitudinal eye protection angle (louvre): 44°
Control gear
  • Driver with constant current output, dimmable by Bluetooth Casambi
Supply voltage
  • 220-240V 50/60Hz
Electrical class
  • Class I
Operating temperature
  • 0 °C to +35 °C

Connection
  • Supplied with a 3G0.75 black 3 m cable - Stripped free end
Mounting
  • Supplied with 2 black suspension wires
LED engine maintenance
  • Perform maintenance by loosening the 4 screws in the straps and removing the gear tray
  • Removable LED modules and driver

Housing
  • Crystal quality PMMA with a rectangular section
End caps, fixing straps and gear unit cover
  • Lacquered steel

Waterproofness
  • IP20 (indoor use)
Fire resistance
  • 650°C

Champagne, Copper
Petrol
Silver
